| Sensitivity | -97dBm |
|---|---|
| Package / Case | Module |
| Power - Output | 2.5dBm |
| Current - Transmitting | 40mA |
| Memory Size | 96kB RAM, 192kB ROM |
| Current - Receiving | 40mA |
| Family | RF Transceivers |
| Frequency | 2.4GHz |
| Data Interface | PCB, Surface Mount |
| Voltage - Supply | 2.7 V ~ 3.6 V |
| Modulation or Protocol | 802.15.4 Zigbee |
| Antenna Connector | PCB, Surface Mount |
| Standard Package | 1 |
| Packaging | Cut Tape (CT) |
| Series | JN5139-001-M0xR |
| Applications | Home/Building Automation, Industrial Control and Monitoring |
| Operating Temperature | -20°C ~ 70°C |
