| 193-9MS | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
Switch DIP OFF ON SPST 9 Piano 0.05A 24VDC Gull Wing 2.54mm SMD Tube
|
||
| 标准包装：20 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage Rating | 24VDC |
|---|---|
| Termination Style | Gull Wing |
| Electrical Life | 7,000 Cycles |
| Washable | No |
| Packaging | Tube |
| Circuit | SPST |
| Features | Epoxy Sealed Terminals |
| Category | Switches |
| Length | 0.986" (25.04mm) |
| Series | 193 |
| Operating Temperature | -40°C ~ 85°C |
| Pitch | 0.100" (2.54mm), Full |
| Contact Finish | Gold |
| Body Material | Plastic |
| Manufacturer | CTS Electrocomponents |
| Mounting Type | Surface Mount, Right Angle |
| Height Above Board | 0.359" (9.12mm) |
| Actuator Type | Piano |
| Part Status | Active |
| Actuator Level | Raised |
| Number of Positions | 9 |
| Family | DIP Switches |
| Current Rating | 50mA |
| ECCN | EAR99 |
| 数据手册： |
|---|
