| Termination | 2 Terminals |
|---|---|
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Size / Dimension | Rectangular/Rounded - 172mm L x 150mm H |
| Category | Fans, Thermal Management |
| Material - Frame | Aluminum |
| Voltage - Rated | 230VAC |
| Noise | 52 dB |
| Family | AC Fans |
| Width | 50.8mm |
| Bearing Type | Ball |
| Static Pressure | 0.700 in H2O (174.4 Pa) |
| Voltage Range | 160 ~ 260VAC |
| Part Status | Active |
| Manufacturer | Orion Fans |
| Air Flow | 235.0 CFM (6.65m³/min) |
| Series | OA172S |
| Power (Watts) | 35W |
| RPM | 3200 RPM |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Fan Type | Tubeaxial |
