NS10145T1R0NNA
NS10145T1R0NNA
  • ACTIVE
  • Nonstandard
Product description : FIXED IND 1UH 8.9A 5.8 MOHM SMD
SPQ：95
Datasheet :
  • Specifications
  • Product Attributes
  • Documents
  • Product reviews

Type Wirewound
Inductance 1µH
Frequency - Self Resonant 116MHz
Size / Dimension 0.398" L x 0.398" W (10.10mm x 10.10mm)
Category Inductors, Coils, Chokes
Height - Seated (Max) 0.191" (4.85mm)
Series NS
Mounting Type Surface Mount
Operating Temperature -40°C ~ 125°C
Packaging Tape & Reel (TR)
Frequency - Test 100kHz
Package / Case Nonstandard
Tolerance ±30%
Current - Saturation 12.54A
Part Status Active
Manufacturer Taiyo Yuden
Material - Core Ferrite
Family Fixed Inductors
Shielding Shielded
DC Resistance (DCR) 5.8 mOhm Max
Current Rating 8.9A
RoHS RoHS compliance
Datasheet：
