| FC-12M 32.7680KA-A3 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
FC-12M Series 32.768 kHz ±20 ppm 12.5 pF -40 to +85°C SMT Crystal Unit
|
||
| 标准包装：1 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Type | kHz Crystal (Tuning Fork) |
|---|---|
| Height | 0.024" (0.60mm) |
| Size / Dimension | 0.081" L x 0.047" W (2.05mm x 1.20mm) |
| Category | Crystals, Oscillators, Resonators |
| Manufacturer | EPSON |
| Family | Crystals |
| Load Capacitance | 12.5pF |
| Frequency | 32.768kHz |
| Packaging | Cut Tape (CT) |
| Package / Case | 2-SMD |
| ESR (Equivalent Series Resistance) | 90 kOhm |
| Part Status | Discontinued |
| Frequency Tolerance | ±20ppm |
| Series | FC-12M |
| Operating Mode | Fundamental |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| ECCN | EAR99 |
