| 597-6901-607F | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
597 Series White 1206 70° 112 mcd Clear 20 mA 3.15 V Surface Mount LED Chip
|
||
| 标准包装：1 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Orientation: | Top View |
|---|---|
| Packaging: | Reel |
| If - Forward Current: | 20 mA |
| Luminous Intensity: | 112 mcd |
| Factory Pack Quantity: | 3000 |
| RoHS: | Details |
| Package / Case: | 1206 |
| Illumination Color: | White |
| Vf - Forward Voltage: | 3.15 V |
| ECCN | EAR99 |
| Viewing Angle: | 70 deg |
| Power Rating: | 70 W |
| Manufacturer: | Dialight |
| Minimum Operating Temperature: | - 55 C |
| Brand: | Dialight |
| LED Size: | 3.2 mm x 1.6 mm x 1.1 mm |
| Product Category: | Standard LEDs - SMD |
| Mounting Style: | SMD/SMT |
| Maximum Operating Temperature: | + 85 C |
