| Switch Function | Off-Mom |
|---|---|
| Actuator Height off PCB, from Pins | 4.00mm |
| Operating Force | 305gf |
| Actuator Material | Resin |
| Actuator Type | Round Button |
| Standard Package | 20 |
| Packaging | Bulk |
| Switch Travel | 0.25mm |
| Family | Tactile Switches |
| Operating Temperature | -40°C ~ 90°C |
| Actuator Orientation | Side Actuated |
| Termination Style | SMD (SMT) Tab |
| Mounting Type | Surface Mount, Right Angle |
| Circuit | SPST-NO |
| Contact Rating @ Voltage | 0.05A @ 32VDC |
| Features | Support Terminal |
| Illumination | Non-Illuminated |
| Series | CF-CA |
| Outline | 7.00mm x 6.70mm |
| 3D Model | CF-CA-1CB4-P411 |
