| 1825421-2 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
SWITCH ROCKER DPDT 3A 125V
|
||
| 标准包装：250 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Switch Function | On-Off-On |
|---|---|
| Electrical Life | 10,000 Cycles |
| Circuit | DPDT |
| Actuator Marking | No Marking |
| Voltage Rating - AC | 125V |
| Color - Actuator/Cap | Black |
| Series | TRD, Alcoswitch |
| Panel Cutout Dimensions | Circular - 11.90mm Dia |
| Operating Temperature | -20°C ~ 80°C |
| Termination Style | Solder Lug |
| Mounting Type | Panel Mount, Threaded Body with Nut |
| Actuator Type | Concave (Curved) |
| Standard Package | 25 |
| Packaging | Bulk |
| Mechanical Life | 50,000 Cycles |
| Family | Rocker Switches |
| RoHS Information | TRD23P10WL04 Statement of Compliance RoHS 2 Statement |
| Current Rating | 3A (AC) |
