| IHLP3232DZER1R0M01 | ||
|---|---|---|
|
|
||
|
||
| Product description : IHLP3232DZ Series 1 µH 18 A ±20% Low Profile High Current IHLP® Inductor | ||
| SPQ：1 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Type | Molded |
|---|---|
| Inductance | 1µH |
| Frequency - Self Resonant | 42MHz |
| Size / Dimension | 0.340" L x 0.322" W (8.64mm x 8.18mm) |
| Category | Inductors, Coils, Chokes |
| Height - Seated (Max) | 0.157" (4.00mm) |
| Family | Fixed Inductors |
| Shielding | Shielded |
| DC Resistance (DCR) | 5.78 mOhm Max |
| Current Rating | 18A |
| ECCN | EAR99 |
| Package / Case | Nonstandard |
| Tolerance | ±20% |
| Current - Saturation | 24A |
| Part Status | Active |
| Manufacturer | Vishay Dale |
| Series | IHLP-3232DZ-01 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Packaging | Cut Tape (CT) |
| Frequency - Test | 100kHz |
