| 206-221ST | ||
|---|---|---|
|
|
||
|
||
| Product description : DIP SWITCH | ||
| SPQ：45 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Voltage Rating | 24VDC |
|---|---|
| Termination Style | PC Pin |
| Electrical Life | 10,000 Cycles |
| Washable | Yes |
| Packaging | Tube |
| Circuit | DPDT |
| Features | Epoxy Sealed Terminals, Tape Seal |
| Category | Switches |
| Number of Positions | 1 |
| Family | DIP Switches |
| Current Rating | 50mA |
| Contact Finish | Gold |
| Body Material | Plastic |
| Manufacturer | CTS Electrocomponents |
| Mounting Type | Through Hole |
| Height Above Board | 0.334" (8.48mm) |
| Actuator Type | Slide (Standard) |
| Part Status | Obsolete |
| Actuator Level | Raised |
| Series | 206 |
| Operating Temperature | -55°C ~ 85°C |
| Pitch | 0.100" (2.54mm), Full |
