| FIT68-1 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
FIT68-1 Series 89.5 uH 2.8 A 108 mOhm Through Hole Vertical Toroid Inductor
|
||
| 标准包装：126 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Inductance | 89.5µH |
|---|---|
| Type | Toroidal |
| Part Status | Active |
| Manufacturer | Triad Magnetics |
| Series | FIT |
| Mounting Type | Through Hole |
| DC Resistance (DCR) | 108 mOhm Max |
| Current Rating | 2.8A |
| Package / Case | Radial |
| Size / Dimension | 0.875" L x 0.475" W (22.22mm x 12.07mm) |
| Category | Inductors, Coils, Chokes |
| Height - Seated (Max) | 0.950" (24.13mm) |
| Family | Fixed Inductors |
| Shielding | Unshielded |
| Packaging | Bulk |
| ECCN | EAR99 |
