| Number of Ports | 1 |
|---|---|
| Voltage - Input | 90 ~ 264 VAC |
| Output Connector | RJ45 (Data, Power) |
| Current - Output | 310mA |
| Standard Package | 1 |
| Approvals | CE, C-Tick, cULus, SAA, TUV |
| Size / Dimension | 2.82" L x 1.97" W x 1.31" H (71.7mm x 50.0mm x 33.2mm) |
| Weight | 0.265 lb (120.2g) |
| Family | Power over Ethernet (PoE) |
| Operating Temperature | 0°C ~ 40°C |
| Power (Watts) - Per Port | 15W |
| Type | Passive Injector |
| Input Connector | International AC Clips (Power), RJ45 (Data) |
| Note | AC Power Clips Sold Separately |
| Voltage - Output | 48V |
| Features | OCP, OVP, SCP |
| Efficiency | 85% |
| Series | PSA15R |
| Mounting Type | Wall Mount |
