| AST2311MATRQ | ||
|---|---|---|
|
|
||
|
||
| Product description : BUZZ PIEZO 9V CIRC 23MM SMD | ||
| SPQ：150 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Termination | Solder Pads |
|---|---|
| Sound Pressure Level | 100dB @ 9V, 10cm |
| Voltage Range | 1 ~ 30V |
| Packaging | Tape & Reel (TR) |
| Washable | Yes |
| Family | Buzzers |
| Mounting Type | Surface Mount |
| Operating Temperature | -30掳C ~ 70掳C |
| Technology | Piezo |
| Input Type | peak-peak Signal |
| Capacitance @ Frequency | 12000pF @ 120Hz |
| Standard Package | 150 |
| Size / Dimension | Circular - 23.00mm Dia x 11.10mm H |
| Voltage - Rated | 9Vp-p |
| Series | AST |
| Operating Mode | Continuous |
| Frequency | 4kHz |
| Current - Supply | 8mA |
| Driver Circuitry | Transducer, Externally Driven |
