| S29AL008J70BFI010 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
S29AL008J: 8 Mb (1 M x 8-Bit/512 K x 16-Bit) CMOS 3 V Boot Sector Flash Memory
|
||
| 标准包装：338 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Memory Size: | 8 Mbit |
|---|---|
| Packaging: | Tray |
| Organization: | 1 M x 8 |
| Interface Type: | Parallel |
| Minimum Operating Temperature: | - 40 C |
| Factory Pack Quantity: | 338 |
| Supply Voltage - Min: | 2.7 V |
| Memory Type: | NOR |
| Supply Current - Max: | 12 mA |
| Data Bus Width: | 8 bit |
| Architecture: | Sector |
| ECCN | EAR99 |
| Timing Type: | Asynchronous |
| Manufacturer: | Cypress Semiconductor |
| Speed: | 70 ns |
| Series: | S29AL008J |
| Operating Temperature Range: | - 40 C to + 85 C |
| Brand: | Cypress Semiconductor |
| RoHS: | Details |
| Package / Case: | BGA-48 |
| Product Category: | Flash Memory |
| Supply Voltage - Max: | 3.6 V |
| Mounting Style: | SMD/SMT |
