| 2N6123 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
80 V 4 A 40 W NPN Through Hole Silicon Power Transistor - TO-220-3
|
||
| 标准包装：400 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Vce Saturation (Max) @ Ib, Ic | 1.4V @ 1A, 4A |
|---|---|
| Package / Case | TO-220-3 |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | 4A |
| Category | Discrete Semiconductor Products |
| Voltage - Collector Emitter Breakdown (Max) | 80V |
| Mounting Type | Through Hole |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 20 @ 1.5A, 2V |
| ECCN | EAR99 |
| Frequency - Transition | 2.5MHz |
| Power - Max | 40W |
| Supplier Device Package | TO-220 |
| Part Status | Active |
| Manufacturer | Central Semiconductor Corp |
| Family | Transistors - Bipolar (BJT) - Single |
| Current - Collector Cutoff (Max) | 1mA |
| Packaging | Tube |
| 数据手册： |
|---|
