| 5-146130-2 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
AMPMODU 6 Position Surface Mount Dual Row 0.1 Inch Straight Breakaway Header
|
||
| 标准包装：3240 | ||
| 数据手册： -- | ||
| ECAD模型:
|
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Row Spacing | 0.100" (2.54mm) |
|---|---|
| Number of Positions Loaded | All |
| Contact Type | Male Pin |
| Part Status | Active |
| Manufacturer | TE Connectivity AMP Connectors |
| Number of Positions | 6 |
| Contact Mating Length | 0.230" (5.84mm) |
| Connector Type | Header, Unshrouded, Breakaway |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Termination | Solder |
| Contact Finish | Gold |
| Color | Black |
| Category | Connectors, Interconnects |
| Series | AMPMODU Mod II |
| Family | Rectangular Connectors - Headers, Male Pins |
| Mounting Type | Surface Mount |
| Contact Finish Thickness | 30µin (0.76µm) |
| Packaging | Tube |
| ECCN | EAR99 |
