| BCM20737S | ||
|---|---|---|
|
|
||
|
||
| 产品描述： | ||
| 标准包装：1820 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Output Power: | 2 dBm |
|---|---|
| Operating Frequency: | 2.402 GHz to 2.48 GHz |
| Packaging: | Tray |
| Program Memory Type: | EEPROM |
| Number of Timers: | 4 |
| Data RAM Size: | 60 kB |
| Core: | ARM Cortex M3 |
| Height: | 1.2 mm |
| Mounting Style: | SMD/SMT |
| Length: | 6.5 mm |
| Manufacturer: | Cypress Semiconductor |
| Data RAM Type: | RAM |
| Program Memory Size: | 512 kB |
| Data Bus Width: | 32 bit |
| Type: | Bluetooth |
| Supply Current Transmitting: | 24 mA |
| Width: | 6.5 mm |
| Sensitivity: | - 94 dBm |
| ADC Resolution: | 16 bit |
| Interface Type: | I2C, SPI, UART |
| Operating Temperature Range: | - 40 C to + 85 C |
| Package / Case: | LGA-48 |
| Maximum Clock Frequency: | 24 MHz |
| Supply Current Receiving: | 24 mA |
| Number of I/Os: | 14 I/O |
| Operating Supply Voltage: | 1.62 V to 3.63 V |
| Brand: | Cypress Semiconductor |
| RoHS: | Details |
| Product Category: | RF System on a Chip - SoC |
