| LIS3LV02DLTR | ||
|---|---|---|
|
|
||
|
||
| Product description : LIS3 Series 3 Axis ±2 G ±6 G Digital Output Voltage Surface Mount Accelero Meter | ||
| SPQ：4000 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Interface Type: | I2C, SPI |
|---|---|
| Packaging: | Reel |
| Sensor Type: | 3-axis |
| Minimum Operating Temperature: | - 40 C |
| Package / Case: | LGA-16 |
| Height: | 0.7 mm |
| Length: | 7.5 mm |
| Output Type: | Digital |
| Operating Supply Voltage: | 2.16 V to 3.6 V |
| Factory Pack Quantity: | 4000 |
| RoHS: | Details |
| Product Category: | Accelerometers |
| Maximum Operating Temperature: | + 85 C |
| Sensitivity: | 1024 LSB/g |
| Width: | 4.4 mm |
| Sensing Axis: | X, Y, Z |
| Supply Voltage - Min: | 2.16 VDC |
| Resolution: | 12 bit, 16 bit |
| Supply Voltage - Max: | 3.6 VDC |
| Manufacturer: | STMicroelectronics |
| Acceleration: | 2 g, 6 g |
| Series: | LIS3 |
| Brand: | STMicroelectronics |
| Operating Supply Current: | 650 uA |
| Type: | Inertial Sensor |
| ECCN | EAR99 |
