| Voltage Rating | 6.3V |
|---|---|
| Package / Case | Radial, Can |
| Capacitance | 47000µF |
| Part Status | Active |
| Category | Capacitors |
| Height - Seated (Max) | 2.047" (52.00mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| ECCN | ECL99 |
| Tolerance | ±20% |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Ripple Current | 3.9A |
| Manufacturer | Nichicon |
| Series | UVK |
| Applications | General Purpose |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Packaging | Bulk |
