| UKZ1E471MHM | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
KZ Series 270 uF 25 V 85°C Ø16 x 25mm LS=7.5mm Radial Aluminum Electrolytic Cap
|
||
| 标准包装：1 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Tolerance | ±20% |
|---|---|
| Package / Case | Radial, Can |
| Capacitance | 470µF |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Category | Capacitors |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| ECCN | EAR99 |
| Voltage Rating | 25V |
| Lead Spacing | 0.295" (7.50mm) |
| Polarization | Polar |
| Part Status | Active |
| Manufacturer | Nichicon |
| Series | UKZ |
| Applications | Audio |
| Lifetime @ Temp. | 1000 Hrs @ 85°C |
| Packaging | Bulk |
