| BRCH064GWZ-3E2 | ||
|---|---|---|
|
|
||
|
||
| Product description : Memory | ||
| SPQ：10 | ||
| Datasheet : |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Grade | Standard |
|---|---|
| Density [bit] | 64K |
| Package | UCSP30L1A |
| Operating Temperature (Max.)[°C] | 85 |
| Vcc(Max.)[V] | 5.5 |
| Standby Current (Max.)[μA] | 2.0 |
| Input Frequency (Max.)[Hz] | 400K |
| Data Retention (Max.)[Year] | 40 |
| I/F | I2C BUS(2-Wire) |
| Bit Format [Word x Bit] | 8K x 8 |
| Operating Temperature (Min.)[°C] | -40 |
| Vcc(Min.)[V] | 1.6 |
| Circuit Current (Max.)[mA] | 2.0 |
| Write Cycle (Max.)[ms] | 5.0 |
| Endurance (Max.)[Cycle] | 106 |
| RoHS | Lead free / RoHS Compliant |
