| Product: | Phototransistors |
|---|---|
| Collector-Emitter Saturation Voltage: | 0.4 V |
| Packaging: | Bulk |
| Maximum On-State Collector Current: | 10.6 mA |
| Manufacturer: | TT Electronics |
| Pd - Power Dissipation: | 100 mW |
| Factory Pack Quantity: | 100 |
| RoHS: | Details |
| Collector- Emitter Voltage VCEO Max: | 30 V |
| Dark Current: | 100 nA |
| Mounting Style: | Through Hole |
| Maximum Operating Temperature: | + 100 C |
| Light Current: | 10.6 mA |
| Width: | 1.63 mm |
| Length: | 4.19 mm |
| Collector-Emitter Breakdown Voltage: | 30 V |
| Peak Wavelength: | 890 nm |
| Minimum Operating Temperature: | - 40 C |
| Brand: | Optek / TT Electronics |
| Product Category: | Phototransistors |
| Height: | 3.81 mm |
| Type: | NPN Silicon Phototransistors |
| Wavelength: | 890 nm |
| ECCN | EAR99 |
