| Mounting Angle: | Straight |
|---|---|
| Switch Function: | ON - OFF - ON |
| Actuator: | Wide (3.8 mm) |
| Voltage Rating AC: | 28 V |
| Contact Form: | SPDT |
| Part # Aliases: | MS-13AAG4 |
| RoHS: | Details |
| Contact Material: | Copper |
| Flammability Rating: | UL 94 V-0 |
| Illumination: | Non-Illuminated |
| Contact Current Rating: | 0.4 VA at 28 VAC/DC |
| ECCN | EAR99 |
| Packaging: | Bulk |
| Travel: | 3.5 mm |
| Manufacturer: | NKK Switches |
| Operating Temperature Range: | - 30 C to + 85 C |
| Factory Pack Quantity: | 1 |
| Brand: | NKK Switches |
| Termination Style: | Solder Lug |
| Product Category: | Slide Switches |
| Contact Plating: | Gold |
| Type: | Miniature Slides |
| Mounting Style: | Panel |
