| Tolerance | ±20% |
|---|---|
| Package / Case | 1206 (3216 Metric) |
| Capacitance | 100µF |
| ESR (Equivalent Series Resistance) | 100 mOhm |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) |
| Category | Capacitors |
| Voltage - Rated | 6.3V |
| Series | POSCAP™ TPH |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 85°C |
| ECCN | EAR99 |
| Failure Rate | * |
| Type | Molded |
| Manufacturer Size Code | A09 |
| Features | General Purpose |
| Part Status | Active |
| Manufacturer | Panasonic Electronic Components |
| Height - Seated (Max) | 0.039" (1.00mm) |
| Family | Tantalum - Polymer Capacitors |
| Lifetime @ Temp. | 1000 Hrs @ 85°C |
| Packaging | Cut Tape (CT) |
