| G125-3041296L4 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
1.25MM M HSG 2X6 POS LAT
|
||
| 标准包装：1 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Product: | Wire Housings |
|---|---|
| Housing Material: | Thermoplastic |
| Manufacturer: | Harwin |
| Series: | G125 |
| Factory Pack Quantity: | 10 |
| Tradename: | GECKO |
| Pitch: | 1.25 mm |
| Termination Style: | Crimp |
| Current Rating: | 2.8 A, 2 A |
| Contact Gender: | Pin (Male) |
| Insulation Resistance: | 1000 MOhms |
| Type: | Plug Housing |
| Packaging: | Bulk |
| Latching Type: | Polarized Lock |
| Voltage Rating: | 240 V, 120 V |
| Operating Temperature Range: | - 65 C to + 150 C |
| Brand: | Harwin |
| RoHS: | Details |
| Number of Positions: | 12 Position |
| Product Category: | Headers & Wire Housings |
| Number of Rows: | 2 Row |
| Contact Plating: | Gold |
| Unit Weight: | 0.010124 oz |
| Mounting Style: | Wire |
