| EP9302-CQZ | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
LQFP 208/ Entry Level, High Performance ARM9 SoC
|
||
| 标准包装：1 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Processor Series: | EP93xx |
|---|---|
| I/O Voltage: | 3.3 V |
| Minimum Operating Temperature: | 0 C |
| Memory Type: | L1 Cache |
| Number of Timers/Counters: | 2 x 16 bit, 1 x 32 bit, 1 x 40 bit |
| Maximum Clock Frequency: | 200 MHz |
| Mounting Style: | SMD/SMT |
| Number of I/Os: | 37 I/O |
| Operating Supply Voltage: | 1.8 V |
| Factory Pack Quantity: | 36 |
| Brand: | Cirrus Logic |
| RoHS: | Details |
| Product Category: | Microprocessors - MPU |
| Packaging: | Tube |
| Interface Type: | Audio, Ethernet, I2S, IrDA, SPI, UART, USB |
| Watchdog Timers: | Watchdog Timer |
| Core: | ARM920T |
| Package / Case: | LQFP-208 |
| Unit Weight: | 0.091254 oz |
| L1 Cache Instruction Memory: | 16 kB |
| Manufacturer: | Cirrus Logic |
| Series: | EP9302 |
| L1 Cache Data Memory: | 16 kB |
| Number of Cores: | 1 Core |
| Data Bus Width: | 32 bit |
| Maximum Operating Temperature: | + 70 C |
