| EKZE250ELL101MF11D | ||
|---|---|---|
|
|
||
|
||
| Product description : KZE Series 25 V 100 uF 6.3 x 11 mm LS =2.5 mm ±20% Radial Electrolytic Capacitor | ||
| SPQ：1 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Voltage Rating | 25V |
|---|---|
| Impedance | 130 mOhm |
| Lead Spacing | 0.098" (2.50mm) |
| Polarization | Polar |
| Part Status | Active |
| Category | Capacitors |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| ECCN | EAR99 |
| Tolerance | ±20% |
| Package / Case | Radial, Can |
| Capacitance | 100µF |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Ripple Current | 162mA @ 120Hz |
| Manufacturer | United Chemi-Con |
| Series | KZE |
| Applications | General Purpose |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Packaging | Bulk |
