| EKMS401VSN821MA50S | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
KMS Series 400 V 820 uF 105 °C Ø 35 x 50 mm Snap-In Aluminum Electrolytic Cap
|
||
| 标准包装：1 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage Rating | 400V |
|---|---|
| Package / Case | Radial, Can - Snap-In |
| Capacitance | 820µF |
| Part Status | Active |
| Category | Capacitors |
| Height - Seated (Max) | 2.067" (52.50mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C ~ 105°C |
| ECCN | EAR99 |
| Tolerance | ±20% |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Ripple Current | 2.69A |
| Manufacturer | United Chemi-Con |
| Series | KMS |
| Applications | General Purpose |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Packaging | Bulk |
