OD6038-12HBXC01A | ||
---|---|---|
|
||
|
||
产品描述:
OD6038 Series 14500 RPM 60 x 60 x 38 mm 76 CFM 12 V 3 Wire Dual Ball Bearing Fan
|
||
标准包装:1 | ||
数据手册: -- |
Termination | 3 Wire Leads |
---|---|
Material - Blade | Polybutylene Terephthalate (PBT) |
Features | Speed Sensor (Tach) |
Size / Dimension | Square - 60mm L x 60mm H |
Category | Fans, Thermal Management |
Material - Frame | Polybutylene Terephthalate (PBT) |
Weight | 0.276 lb (125.19g) |
Series | OD6038 |
Power (Watts) | 28.8W |
RPM | 14500 RPM |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
Fan Type | Tubeaxial |
ECCN | EAR99 |
Static Pressure | 2.400 in H2O (597.8 Pa) |
Approvals | TUV, UR |
Voltage Range | 10.8 ~ 13.2VDC |
Part Status | Active |
Manufacturer | Orion Fans |
Air Flow | 76.0 CFM (2.15m³/min) |
Voltage - Rated | 12VDC |
Noise | 64 dB |
Family | DC Fans |
Width | 38mm |
Bearing Type | Ball |
Current Rating | 2.1A |
