B78108S1224J
B78108S1224J
  • ACTIVE
  • Axial
  • EAR99
Product description : BC Series 4 x 9.2 mm 220 uH ±5% 250 mA Axial Through Hole Inductor
SPQ:5000
Datasheet :
  • Specifications
  • Product Attributes
  • Documents
  • Product reviews
Type Wirewound
Inductance 220µH
Frequency - Self Resonant 3.7MHz
Size / Dimension 0.157" Dia x 0.362" L (4.00mm x 9.20mm)
Category Inductors, Coils, Chokes
Material - Core Ferrite
Family Fixed Inductors
Shielding Unshielded
DC Resistance (DCR) 3.3 Ohm Max
Current Rating 250mA
ECCN EAR99
Package / Case Axial
Tolerance ±5%
Q @ Freq 70 @ 796kHz
Part Status Active
Manufacturer EPCOS (TDK)
Series BC
Mounting Type Through Hole
Operating Temperature -55°C ~ 125°C
Packaging Cut Tape (CT)
Frequency - Test 796kHz
