| 4715VL-05W-B60-E00 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
119x25mm, 230VAC, 70.6 CFM, 2700 RPM, 38.0 dB, Aluminum Case, Ball Bearing, Flan
|
||
| 标准包装：40 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Termination | 2 Wire Leads |
|---|---|
| Material - Blade | Plastic |
| Voltage Range | 18 ~ 27.6VDC |
| Part Status | Active |
| Manufacturer | NMB Technologies Corporation |
| Air Flow | 189.9 CFM (5.38m³/min) |
| Voltage - Rated | 24VDC |
| Noise | 59.5 dB(A) |
| Family | DC Fans |
| Width | 38mm |
| Bearing Type | Ball |
| Current Rating | 0.740A |
| Static Pressure | 0.920 in H2O (229.2 Pa) |
| Approvals | CE, UR, VDE |
| Size / Dimension | Square - 120mm L x 120mm H |
| Category | Fans, Thermal Management |
| Material - Frame | Plastic |
| Weight | 0.816 lb (370.13g) |
| Series | 4715VL |
| Power (Watts) | 17.8W |
| RPM | 5000 RPM |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) |
| Fan Type | Tubeaxial |
| ECCN | EAR99 |
