| Circuit | SPDT |
|---|---|
| Switch Function | On-Off-On |
| Actuator Length | 2.50mm |
| Termination Style | PC Pin |
| Features | Epoxy Sealed Terminals |
| Electrical Life | 50,000 Cycles |
| Category | Switches |
| Switch Travel | 2.50mm |
| Operating Force | 260gf |
| Family | Slide Switches |
| Operating Temperature | -30°C ~ 85°C |
| Packaging | Tray |
| Current Rating | 0.4VA (AC/DC) |
| Actuator Type | Standard |
| Contact Finish | Gold |
| Voltage Rating - AC | 28V |
| Voltage Rating - DC | 28V |
| Part Status | Active |
| Manufacturer | NKK Switches |
| Contact Material | Phosphor Bronze |
| Series | AS |
| Mechanical Life | 50,000 Cycles |
| Mounting Type | Through Hole, Right Angle, Vertical |
| Contact Timing | Non-Shorting (BBM) |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled |
| ECCN | ECL99 |
