| USR1H010MDD | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
SR Series 1 uF 50 V 85°C Ø4 x 7 mm LS=1.5 mm Radial Aluminum Electrolytic Cap
|
||
| 标准包装：200 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage Rating | 50V |
|---|---|
| Package / Case | Radial, Can |
| Capacitance | 1µF |
| Size / Dimension | 0.157" Dia (4.00mm) |
| Ripple Current | 10mA @ 120Hz |
| Manufacturer | Nichicon |
| Series | USR |
| Applications | General Purpose |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Packaging | Bulk |
| Tolerance | ±20% |
| Lead Spacing | 0.059" (1.50mm) |
| Polarization | Polar |
| Part Status | Active |
| Category | Capacitors |
| Height - Seated (Max) | 0.315" (8.00mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| ECCN | EAR99 |
登录之后就可发表评论
Availability2Request Stock Notification
Supplier Stock
Offline Manufacture or Manufacture authorized supplier owned stock and price , need double confirmation and share out from them
| stock | 143884 | Update On 2025-05-27 |
|---|---|---|
| Lead-Time | -- | |
| SPQ/MOQ | 200/1 | |
| Location | -- | |
| DateCode | 2122 |
