| RBM-0505D/P | ||
|---|---|---|
|
|
||
|
||
| Product description : RBM Series 1 W Dual Output -5 / 5 V DC/DC Converter - SIP-6 | ||
| SPQ：30 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Voltage - Isolation | 3kV (3000V) |
|---|---|
| Type | Isolated Module |
| Power (Watts) - Manufacture Series | 1W |
| Efficiency | 78% |
| Power (Watts) - Max | 1W |
| Standard Package | 30 |
| Packaging | Tube |
| Voltage - Output 1 | 5V |
| Family | DC DC Converters |
| Voltage - Input (Min) | 4.5V |
| ECCN | EAR99 |
| Number of Outputs | 2 |
| Current - Output (Max) | 100mA, 100mA |
| Size / Dimension | 0.65" L x 0.24" W x 0.30" H (16.5mm x 6.0mm x 7.7mm) |
| Mounting Type | Through Hole |
| Package / Case | 6-SIP Module (5 Leads) |
| Features | SCP |
| Voltage - Input (Max) | 5.5V |
| Series | ECONOLINE RBM |
| Voltage - Output 2 | -5V |
| Operating Temperature | -40°C ~ 85°C |
