| R2D-0509 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
CONV DC/DC 2W 05VIN +/-09VOUT
|
||
| 标准包装：33 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage - Isolation | 1kV (1000V) |
|---|---|
| Type | Isolated Module |
| Power (Watts) - Manufacture Series | 2W |
| Efficiency | 80% |
| Power (Watts) - Max | 2W |
| Standard Package | 33 |
| Packaging | Tube |
| Voltage - Output 1 | 9V |
| Family | DC DC Converters |
| Voltage - Input (Min) | 4.5V |
| ECCN | ECL99 |
| Number of Outputs | 2 |
| Current - Output (Max) | 111mA, 111mA |
| Size / Dimension | 0.60" L x 0.42" W x 0.35" H (15.2mm x 10.7mm x 9.0mm) |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD Module (6 Leads) |
| Features | SCP |
| Voltage - Input (Max) | 5.5V |
| Series | ECONOLINE R2D |
| Voltage - Output 2 | -9V |
| Operating Temperature | -40掳C ~ 100掳C |
