| KLKD007.T | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
KLKD Series Fast-Acting 600 V 7 A Ø 10.31 x 38.1 mm Midget Cartridge Fuse
|
||
| 标准包装：1 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Package / Case | 5AG, 10mm x 38.1mm |
|---|---|
| Voltage Rating - DC | 600V |
| Size / Dimension | 0.406" Dia x 1.500" L (10.31mm x 38.10mm) |
| DC Cold Resistance | 0.0205 Ohm |
| Online Catalog | POWR-GARD® KLKD Series |
| Family | Fuses |
| Melting I²t | 105.143 |
| Packaging | Bulk |
| RoHS | Lead free / RoHS Compliant |
| Voltage Rating - AC | 600V |
| Approvals | CSA, UL, VDE |
| Fuse Type | Cartridge, Ceramic |
| Response Time | Fast |
| Series | KLKD |
| Mounting Type | Holder |
| Breaking Capacity @ Rated Voltage | 100kA AC, 50kA DC |
| Current Rating | 7A |
| ECCN | EAR99 |
