| 4SEPC560MW | ||
|---|---|---|
|
|
||
|
||
| Product description : CAP ALUM POLY 560UF 20% 4V T/H | ||
| SPQ：1 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Tolerance | ±20% |
|---|---|
| Package / Case | Radial, Can |
| Lead Spacing | 0.098" (2.50mm) |
| ESR (Equivalent Series Resistance) | 7 mOhm |
| Part Status | Active |
| Category | Capacitors |
| Height - Seated (Max) | 0.354" (9.00mm) |
| Family | Aluminum - Polymer Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 105°C |
| Voltage Rating | 4V |
| Type | Polymer |
| Capacitance | 560µF |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Ripple Current | 5.6A |
| Manufacturer | Panasonic Electronic Components |
| Series | OS-CON™, SEPC |
| Applications | General Purpose |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Packaging | Bulk |
