| LB-302MP | ||
|---|---|---|
|
||
|
||
| 产品描述：
DISPLAY 7SEG 7.62MM 2DGT GRN CC
|
||
| 标准包装：500 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Number of Characters | 2 |
|---|---|
| Package / Case | 10-DIP (0.400\", 10.16mm) |
| Standard Package | 500 |
| Size / Dimension | 0.591\" H x 0.610\" W x 0.283\" D (15.00mm x 15.50mm x 7.20mm) |
| Display Type | 7-Segment |
| Current - Test | 10mA |
| Family | Display Modules - LED Character and Numeric |
| Millicandela Rating | 9mcd |
| Part Status | Not For New Designs |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Power Dissipation (Max) | 60mW |
| Catalog Drawings | LB-302 Series Top |
| Color | Green |
| Digit/Alpha Size | 0.30\" (7.62mm) |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Wavelength - Peak | 563nm |
| Common Pin | Common Cathode |
| Categories | Optoelectronics -> Display Modules - LED Character and Numeric |
| Manufacturer | Rohm Semiconductor |
