| GBC13DABN-M30 | ||
|---|---|---|
|
|
||
|
||
| Product description : GBC13DABN Series 13 Position 2.54 mm Dual Row Surface Mount Pin Header | ||
| SPQ：1 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Contact Finish | Gold |
|---|---|
| Mounting Type | Surface Mount |
| Row Spacing | 0.100" (2.54mm) |
| Contact Type | Male Pin |
| Alternate Length | S2351E-11-ND - CONN HEADER 22POS .100 DUAL SMD S2351E-09-ND - CONN HEADER 18POS .100 DUAL SMD S2351E-07-ND - CONN HEADER 14POS .100 DUAL SMD S2351E-05-ND - CONN HEADER 10POS .100 DUAL SMD S2351E-03-ND - CONN HEADER 6POS .100 DUAL SMD S2351E-02-ND - CONN |
| Color | Black |
| Packaging | Bulk |
| Number of Positions | 26 |
| Contact Mating Length | 0.230" (5.84mm) |
| Number of Rows | 2 |
| ECCN | EAR99 |
| Number of Positions Loaded | All |
| Contact Finish Thickness | 10µin (0.25µm) |
| Termination | Solder |
| Catalog Drawings | S23x1E Series Dual Straight |
| Standard Package | 1 |
| PCN Design/Specification | Temp/Time for Nylon 9T 27/Oct/2010 |
| Online Catalog | GxC and PxC |
| Family | Rectangular Connectors - Headers, Male Pins |
| Connector Type | Header, Unshrouded, Breakaway |
| Pitch | 0.100" (2.54mm) |
