| ACSC56-41CGKWA-F01 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
Dual Digit Green 0.56 Seven Segment Common Cathode Display Surface Mount
|
||
| 标准包装：400 | ||
| 数据手册： |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Number of Characters | 1 |
|---|---|
| Package / Case | 10-SMD (No Lead) |
| Size / Dimension | 0.669" H x 0.488" W x 0.148" D (17.00mm x 12.40mm x 3.75mm) |
| Digit/Alpha Size | 0.56" (14.22mm) |
| Manufacturer | Kingbright |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Wavelength - Peak | 574nm |
| Common Pin | Common Cathode |
| Packaging | Cut Tape (CT) |
| Power Dissipation (Max) | 75mW |
| Color | Green |
| Part Status | Active |
| Category | Optoelectronics |
| Display Type | 7-Segment |
| Current - Test | 20mA |
| Family | Display Modules - LED Character and Numeric |
| Millicandela Rating | 25mcd |
| ECCN | EAR99 |
