| 63RX30220M12.5X20 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
Elco Rad 220uF 63V 12.5X20mm 130C 4000h
|
||
| 标准包装：1 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage Rating | 63V |
|---|---|
| Impedance | 100 mOhm |
| Type | Polar |
| Capacitance | 220µF |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Ripple Current | 574mA |
| Series | RX30 |
| Applications | Automotive |
| Lifetime @ Temp. | 4000 Hrs @ 130°C |
| Polarization | Polar |
| Categories | Capacitors ->Aluminum Electrolytic Capacitors |
| Ripple Current @ Low Frequency | 574mA @ 120Hz |
| Packaging | Bulk |
| Tolerance | ±20% |
| Package / Case | Radial, Can |
| Lead Spacing | 0.197" (5.00mm) |
| Standard Package | 1,000 |
| Packaging | Bulk |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 130°C |
| Polarization | Polar |
| Categories | Capacitors ->Aluminum Electrolytic Capacitors |
| Ripple Current @ Low Frequency | 574mA @ 120Hz |
| Packaging | Bulk |
