| 30BQ100TR | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
30BQ100 Series 100 V 3 A Surface Mount Schottky Rectifier - SMC
|
||
| 标准包装：3000 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Operating Temperature - Junction | -55°C ~ 175°C |
|---|---|
| Package / Case | DO-214AB, SMC |
| Catalog Drawings | SMC Series Top SMC Series Side |
| Packaging | Tape & Reel (TR) |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Family | Diodes, Rectifiers - Single |
| Voltage - DC Reverse (Vr) (Max) | 100V |
| ECCN | EAR99 |
| Current - Average Rectified (Io) | 3A |
| Supplier Device Package | SMC |
| Standard Package | 3,000 |
| Diode Type | Schottky |
| Current - Reverse Leakage @ Vr | 500µA @ 100V |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Max) @ If | 790mV @ 3A |
