| 189-025-513R491 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
D-Sub Connector Receptacle, Female Sockets 25, 25 Position Board Edge, Through
|
||
| 标准包装：25 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Connector Style | D-Sub - Stacked |
|---|---|
| Contact Finish | Gold |
| Product Training Modules | D-Sub Connectors |
| Housing Material | Polyamide (PA9T), Nylon 9T |
| Contact Finish Thickness | Flash |
| Contact Type | Signal |
| Standard Package | 25 |
| Color | Black |
| Packaging | Tray |
| Number of Positions | 25, 25 |
| Operating Temperature | -55掳C ~ 105掳C |
| Current Rating | 5A |
| ECCN | EAR99 |
| Shell Material, Finish | Steel, Nickel Plated |
| Shell Size, Connector Layout | 3 (DB, B); 3 (DB, B) |
| Other Related Documents | 189-025-513R491 Material Declaration |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Termination | Solder |
| Catalog Drawings | 178, 179, 189 Series Front |
| Features | Board Lock, Grounding Indents, Shielded |
| Flange Feature | Housing/Shell (4-40) |
| Series | 189 |
| Family | D-Sub Connectors |
| Connector Type | Receptacle, Female Sockets |
| Number of Rows | 2, 2 |
