| EEU-FC1E472 | ||
|---|---|---|
|
|
||
|
||
| Product description : EEU-FC Series 25 V 4700 uF Ø 18 x 35.5 mm LS=7.5 mm 105 °C Low ESR Electrolytic | ||
| SPQ：50 | ||
| Datasheet : -- |
- Specifications
- Product Attributes
- Documents
- Product reviews
| Voltage Rating | 25V |
|---|---|
| Impedance | 15 mOhm |
| Product Training Modules | LED Lighting Components |
| Height - Seated (Max) | 1.398" (35.50mm) |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Catalog Drawings | FC Series_35.5 x 0.80 FC Series_18.0 x 7.5 (2) |
| Online Catalog | FC Series Through Hole |
| Family | Aluminum Capacitors |
| Operating Temperature | -55°C ~ 105°C |
| Tolerance | ±20% |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Applications | AEC-Q200 |
| Packaging | Bulk |
| Capacitance | 4700µF |
| Ripple Current | 3.128A |
| Series | FC |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| RoHS | Lead free / RoHS Compliant |
