| 30R600UF | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
30R Series 30 V 6 A Radial Lead POLYFUSE® Resettable PTC
|
||
| 标准包装：200 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Package / Case | Radial, Disc |
|---|---|
| Lead Spacing | 0.402" (10.20mm) |
| Part Status | Active |
| Category | Circuit Protection |
| Height - Seated (Max) | 1.060" (26.80mm) |
| Current - Max | 40A |
| Mounting Type | Through Hole |
| Current - Hold (Ih) (Max) | 6A |
| Packaging | Bulk |
| R Min/Max | 0.005 ~ 0.040 Ohm |
| Size / Dimension | 0.650" L x 0.118" W (16.50mm x 3.00mm) |
| Time to Trip | 16s |
| Manufacturer | Littelfuse Inc. |
| Series | POLY-FUSE®, 30R |
| Family | PTC Resettable Fuses |
| Voltage - Max | 30V |
| Current - Trip (It) | 12A |
| ECCN | EAR99 |
