| BCM380P475T1K2A30 | ||
|---|---|---|
|
|
||
|
||
| 产品描述：
Unregulated 1200 W 380 V input 47.5 V output DC-DC Bus Converter Module
|
||
| 标准包装：1 | ||
| 数据手册： -- |
- 规格参数
- 产品特性
- 技术文档
- 产品评论
| Voltage - Isolation | 4.242kV (4242V) |
|---|---|
| Package / Case | Module |
| Current - Output (Max) | 25.26A |
| Features | OCP, OTP, SCP, UVLO |
| Part Status | Active |
| Efficiency | 97.9% |
| Voltage - Input (Max) | 410V |
| Series | VI Chip® BCM® |
| Voltage - Input (Min) | 260V |
| Mounting Type | Through Hole |
| Power (Watts) - Max | 1200W |
| ECCN | EAR99 |
| Number of Outputs | 1 |
| Type | Bus Converter Module |
| Power (Watts) - Manufacture Series | 1200W |
| Size / Dimension | 2.49" L x 0.90" W x 0.29" H (63.3mm x 22.8mm x 7.3mm) |
| Category | Power Supplies - Board Mount |
| Manufacturer | Vicor Corporation |
| Voltage - Output 1 | 47.5V |
| Family | DC DC Converters |
| Applications | ITE (Commercial) |
| Operating Temperature | -40°C ~ 125°C |
| Packaging | Tray |
