| Voltage Rating | 6.3V |
|---|---|
| Impedance | 59 mOhm |
| Lead Spacing | 0.138" (3.50mm) |
| Polarization | Polar |
| Part Status | Active |
| Category | Capacitors |
| Height - Seated (Max) | 0.689" (17.50mm) |
| Family | Aluminum Capacitors |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Categories | Capacitors ->Aluminum Electrolytic Capacitors |
| Voltage - Rated | 6.3V |
| Tolerance | ±20% |
| Package / Case | Radial, Can |
| Capacitance | 1000µF |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Ripple Current | 750mA @ 120Hz |
| Manufacturer | Rubycon |
| Series | ZLJ |
| Applications | General Purpose |
| Lifetime @ Temp. | 9000 Hrs @ 105°C |
| Packaging | Bulk |
| Categories | Capacitors ->Aluminum Electrolytic Capacitors |
| Voltage - Rated | 6.3V |
