FAA1-08025NBHW31

FAA1-08025 Series 2800 RPM 80 x 80 x 25 mm 21 CFM 115 V 2 Wire AC Axial Fan

Manufacturer Qualtek Electronics Corp. MPN FAA1-08025NBHW31 SPQ 1 ECCN EAR99 Schedule B -- RoHS -- Datasheet --

SP1027 Dollar $32.9654 RMB ￥273.799 Stock type SP1027 Stock num 70 Stepped num price 10+ $32.9654 30+ $30.52725 50+ $29.72125 100+ $27.3637 250+ $26.69875

Quote

Demand quantity		Target price
Contact number		name
company		email

Product parameter

-Termination	2 Wire Leads
-Material - Blade	Plastic
-Size / Dimension	Square - 80mm L x 80mm H
-Category	Fans, Thermal Management
-Material - Frame	Aluminum
-Weight	0.463 lb (210.01g)
-Series	FAA1-08025
-Power (Watts)	7.00W
-RPM	2800 RPM
-Operating Temperature	14 ~ 158°F (-10 ~ 70°C)
-Fan Type	Tubeaxial
-ECCN	EAR99
-Static Pressure	0.125 in H2O (31.1 Pa)
-Approvals	CE, TUV, UL
-Part Status	Active
-Manufacturer	Qualtek
-Air Flow	21.0 CFM (0.595m³/min)
-Voltage - Rated	115VAC
-Noise	27.8 dB(A)
-Family	AC Fans
-Width	25mm
-Bearing Type	Ball
-Current Rating	0.060A
