| -Steps per Revolution | 48 |
| -Mounting Hole Spacing | 1.370" (34.90mm) |
| -Rotor Inertia | 1.1gcm² |
| -Termination Style | Wire Leads |
| -Coil Type | Unipolar |
| -Size / Dimension | Round - 1.030" Dia (26.16mm) |
| -Category | Motors, Solenoids, Driver Boards/Modules |
| -Weight | 0.075 lb (34.02g) |
| -Series | 26M |
| -Family | Stepper Motors |
| -Operating Temperature | -20°C ~ 70°C |
| -Current Rating | 0.11A |
| -Type | Permanent Magnet |
| -Accuracy | ±15% |
| -Step Angle | 7.5° |
| -Diameter - Shaft | 0.079" (2.00mm) |
| -Features | Round Shaft |
| -Part Status | Active |
| -Manufacturer | Portescap |
| -Voltage - Rated | 12VDC |
| -Coil Resistance | 110 Ohms |
| -Length - Shaft and Bearing | 0.445" (11.30mm) |
| -Torque - Holding (oz-in / mNm) | 1.3 / 9.2 |
