| -Max Propagation Delay @ V, Max CL |
10ns @ 6V, 50pF |
| -Voltage - Supply |
2 V ~ 6 V |
| -Logic Type |
Inverter |
| -Part Status |
Active |
| -Manufacturer |
Toshiba Semiconductor and Storage |
| -Number of Circuits |
3 |
| -Number of Inputs |
3 |
| -Family |
Logic - Gates and Inverters |
| -Operating Temperature |
-40°C ~ 85°C |
| -Packaging |
Cut Tape (CT) |
| -Package / Case |
8-VFSOP (0.091", 2.30mm Width) |
| -Supplier Device Package |
US8 |
| -Logic Level - Low |
0.3 V ~ 1.2 V |
| -Category |
Integrated Circuits (ICs) |
| -Logic Level - High |
1.7 V ~ 4.8 V |
| -Series |
TC7WU |
| -Current - Output High, Low |
5.2mA, 5.2mA |
| -Mounting Type |
Surface Mount |
| -Current - Quiescent (Max) |
1µA |
